Duracomm HE1U-5012-BMS-MU

Product Description

The HE1U-5012-BMS-MU is an Internet Ready Heavy Duty AC to DC 750 Watt Power Supply with a 120 Watt smart charger and low voltage disconnect in a 1U chassis. The HE1U-5012-BMS-MU comes with power factor correction, and four layers of protection against overload, over voltage, over temperature, and short circuit. This model also comes with a manual battery disconnect switch, internal power supply ON/OFF remote control, and DC-OK.

The new internal Remote Monitoring and Control Unit (RMCU), provides the ability to remotely monitor the AC voltage, power supply current and voltage, battery voltage and current, and internal temperature, as well as the ability to remotely control the ON/OFF State of the power supply unit, all via the internet using any standard web browser. A mobile-friendly version of the status page is also included.

Users that have access to the network can view the status of the power supply, control outputs, and the alarm conditions, as well as download a .CSV file of logged states. Administrative users can access the setup screens and change the control settings by logging into the RMCU via the browser. Alarm conditions are configurable, and can include over and under thresholds. Alarm notifications can be configured by an administrator to send email and SNMP traps. Setups are saved in non-volatile RAM, and a battery backed up real-time clock is provided to timestamp information logged to the internal SD card. Logging rate is user settable.

The HE1U-5012-BMS-MU comes with the DuraComm three-year warranty.

Product Specifications

Output Current (Amps):
Output Voltage VDC:
Input Voltage VAC:
110 or 220
Charging Current Amps:
Disconnect / Reconnect VDC:
10.4 / 12.5
Suggested Battery Capacity:
60-120 Ah
Panel Height:
Weight (lbs):
1.75"H x 19"W x 13"D
Battery Disconnect Switch:


Please review our return policy here

Original price $ 1,464.00 - Original price $ 1,464.00
Original price
$ 1,464.00
$ 1,464.00 - $ 1,464.00
Current price $ 1,464.00
