BCD-GMRS 50W UHF Duplexer
BCD-GMRS 50W UHF Duplexer
GMRS 50W Duplexer – Pre-Tuned for the 8 Main Repeater Channels
The GMRS 50W Duplexer is factory pre-tuned for the 8 standard GMRS repeater main channels, providing excellent TX/RX isolation and low signal loss for clean, reliable communication. Ideal for 50-watt GMRS repeater systems, this compact, rugged duplexer is ready to install and perform right out of the box.
Key Features
-
✅ Pre-Configured Frequencies:
TX 462.550–462.725 MHz / RX 467.550–467.725 MHz (5 MHz separation) -
📡 High Performance:
≤ 1.1dB insertion loss, ≥ 75 dB isolation, ≥ 18 dB return loss -
💪 Power Handling:
Up to 50 Watts continuous duty -
⚙️ Built for Reliability:
Precision-tuned, tested, and ready for use with BridgeCom Systems BCR-GMRS and compatible repeaters -
🧩 Compact & Durable:
Aluminum housing with N-female connectors for easy integration
Specifications
| Frequency Range | 462–467 MHz |
| Impedance | 50 Ω |
| Connectors | N-Female |
| Size (H×W×D) | 32 × 155 × 240 mm |
| Weight | 1.20 kg |
| Operating Temp | −25 °C ~ +60 °C |
| Power Rating | 50W |
| Frequency Separation | 5 MHz |
| Insertion Loss | Typically ≤ 0.98dB Max. 1.1dB |
| Isolation | ≥75dB |
| Return Loss | ≥18db |
Includes
-
GMRS 50W Duplexer (Pre-Tuned)
- Test & alignment report
