Duracomm LPX-18BC Power Supply with Built-In Battery Charger

Specifications:

• AC Input Voltage:
• 115 or 230 VAC (Switch selectable)
• DC Output Voltage:
• Ch. 1=13.8 VDC

• Ch. 2=13.6 VDC
• Output Ripple:
• 120mV P-P @ full load
• Rated Current (max.):
• 13.5 amps (15 amps - No Batt) 18A Int.=CH.1
• 1.5 amps=CH.2
• Duty Cycle:
• Continuous = 100% Industry Continuous Comm. Service (CCS)
• Overload:
• 120~160% (CH.1), 1.51~1.7A(CH.2) rated output
• Fold back, repower on to recover.
• UPS mode: Protected by internal fuse
• Over Voltage:
• 15.87~18.63V max. Shut down - re-power on to recover
• Over Temperature:
• 75 degrees Celsius (+-10 degrees) Shut down, Auto recover
• Load Regulation:
• 1.0% No load to full load
• Line Regulation:
• 0.5%
• Inrush Current (max.)
• Cold Start 35A/230VAC
• AC Current

• 4.6A/115VAC
• 2.6A/230VAC
• Rated Power

• 250 Watts
• Cooling
• Forced air, Fan on - 45 degrees Celsius
• Working Temperature

• - 10 ~ 70 degrees Celsius
• Efficiency

• 80% typical
• Safety

• UL 60950-1, 2nd:2011 UL/CUL recognized
• Quality Assurance

• ISO 9001 standards
• Dimensions

• 217 x 180 x 50 mm
• Weight

• 3.5lbs / 1.6Kgs.
• The LP-18BC will charge any type of lead acid battery such as AGM.
